English - 5 -
Environmental Information
This television is designed to be environmentally
friendly. To reduce energy consumption, you can
follow these steps:
If you set the Energy Saving option to Minimum,
Medium, Maximum or Auto, the TV will adjust the
energy consumption accordingly. Set as Off to turn
this setting off. If you like to set the backlight to a
fixed value set as Custom, highlight Backlight (will
be located under the Energy Saving setting) and
then adjust manually using the Left or Right directional
button on the remote.
Note: Available energy saving options may differ depending on
the selected Mode in the Settings>Picture menu.
The Energy Saving option can be found in the
Settings>Picture menu. Go to Home screen and
highlight Settings in the navigation carousel and press
OK to access the Settings menu. Note that some
picture settings will be unavailable to be changed.
YoucanalsoturnthescreenoffusingtheScreen Off
option,ifyouwanttohearthesoundonlyanddon't
need to watch. If pressed Right button or Left button
consecutively Screen Off option will be selected and
“Screen will be off in 15 seconds.”messagewillbe
displayedonthescreen.SelectProceed and press
OK to turn the screen off immediately. If you don’t
press any button, the screen will be off in 15 seconds.
Press any button on the remote or on the TV to turn
the screen on again.
Note: The Screen Off option is not available, if the Mode is
set to Game.
When the TV is not in use, please switch off or
disconnect the TV from the mains plug. This will also
reduce or stop the energy consumption.
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way
when using the wall-hanging bracket or repacking
the TV.
• Put the TV onto a work table with the screen panel
down on the clean and soft cloth. Leave the stand(s)
protruding over the edge of the surface.
• Unscrew the screws that fixing the stand(s).
• Remove the stand(s).
When using the wall-hanging bracket
Please contact your local Panasonic dealer to
purchase the recommended wall-hanging bracket.
Holes for wall-hanging bracket installation;
Rear of the TV
a
b
43” 50” 55” 65”
a (mm) 100 200 200 400
b (mm) 100 200 200 200
View from the side
c
VESA
Bracket
e
d
(d) (e)
43” 50”
55”
43” 50”
55”
Diameter M4 M6 M4 M6
Depth of screw (c)
min. 7 mm 5 mm
max. 10 mm 6 mm
(d) (e)
65”
Depth of screw (c)
min. 7 mm
max. 10 mm
Diameter M6
Note: The screws for fixing the TV onto the wall-hanging
bracket are not supplied with the TV.
