30
Check you can get Freeview HD in your area. Text your postcode, followed by your house number or
name to 80560
*
. Or visit freeview.co.uk
*
e.g. NW96NY1 (Costs no more than a normal text.)
To get the most up to date service from Freeview it is important for Freeview customers to retune from time to time.
How do I re-tune my Freeview TV ?
This is a quick reference. If you have any problems, check the Operating Instructions or ask a friend or family
member to show you how. Alternatively, go to your local electrical retailer, contact your local Panasonic dealer or
visit freeview.co.uk/retune
Re-tuning only takes a few minutes, just follow the steps below:
1. Press the TV button to select DVB mode.
2. Press the MENU button to open the main menu.
3. [Setup]
[DVB Tuning Menu] [Auto Setup]
Please note: most digital TV recorders will keep your original recordings after running a re-tune but you will need to
reset any future recordings.
Specifications
32-inch model
39-inch model
50-inch model
Model No. TX-L32XM6B TX-L39EM6B TX-L50EM6B
Dimensions (W × H × D)
741 mm × 513 mm ×
207 mm (With Pedestal)
741 mm × 448 mm ×
55 mm (TV only)
890 mm × 593 mm ×
217 mm (With Pedestal)
890 mm × 531 mm ×
60 mm (TV only)
1,159 mm × 738 mm ×
298 mm (With Pedestal)
1,159 mm × 693 mm ×
69 mm (TV only)
Mass
8.0
Net (With Pedestal)
7.0 Net (TV only)
12.0 Net (With Pedestal)
10.0 Net (TV only)
21.0 Net (With Pedestal)
17.5 Net (TV only)
Power source AC 220-240 V, 50 / 60 Hz
Panel LED LCD panel
Sound
Speaker
(90 mm × 25 mm) × 2
8 Ω
(100 mm × 30 mm) × 2, 8 Ω
Audio output 10 W (5 W + 5 W) 20 W (10 W + 10 W)
Headphones M3 (3.5 mm) stereo mini Jack × 1
Operating conditions
Temperature: 0 °C - 35 °C
Humidity: 20 % - 80 % RH (non-condensing)
Connection terminals
AV1 input / output SCART (Audio/Video in, Audio/Video out, RGB in)
AV2 input
(COMPONENT /
VIDEO)
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 Ω)
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
Y 1.0 V[p-p] (including synchronisation)
P
B, PR ±0.35 V[p-p]
HDMI 1 / 2 input
TYPE A Connectors
HDMI1: Content Type
HDMI2: Content Type, Audio Return Channel
●
This TV supports “HDAVI Control 5” function.
Card slot Common Interface slot (complies with CI Plus) × 1
ETHERNET RJ45, IEEE802.3 10BASE-T / 100BASE-TX
USB USB2.0 DC 5 V, Max. 500 mA
DIGITAL AUDIO
output
PCM / Dolby Digital / DTS, Fibre optic
