Specifications
Frequently Asked Questions
FAQs, etc.
67
Specifications
TX-L32C20LA
Power Source AC 220-240 V, 50 Hz
Rated Power Consumption 90 W
Standby Power Consumption
0.4 W
13 W (With monitor out recording)
Display
panel
Aspect Ratio 16:9
Visible screen size
80 cm (diagonal)
697 mm (W) × 392 mm (H)
Number of pixels 1,049,088 (1,366 (W) × 768 (H))
Sound
Speaker 160 mm × 42 mm × 2 pcs, 8
:
Audio Output 10 W (5 W + 5 W), 10% THD
Headphones M3 (3.5 mm) stereo mini Jack × 1
Receiving Systems /
Band name
PAL B, G, H, I, SECAM B, G, SECAM L, L’
VHF E2 - E12 VHF H1 - H2 (ITALY)
VHF A - H (ITALY) VHF A - J (IRELAND) UHF E21 - E69
CATV (S01 - S05) CATV S1 - S10 (M1 - M10)
CATV S11 - S20 (U1 - U10) CATV S21 - S41 (Hyperband)
PAL D, K, SECAM D, K
VHF R1 - R2 VHF R3 - R5
VHF R6 - R12 UHF E21 - E69
PAL 525/60 Playback of NTSC tape from some PAL Video re cord ers (VCR)
M.NTSC Playback from M.NTSC Video recorders (VCR)
NTSC (AV input only) Playback from NTSC Video recorders (VCR)
DVB-T Digital terrestrial services (MPEG2 and MPEG4-AVC
(H.264))
DVB-C Digital cable services (MPEG2 and MPEG4-AVC
(H.264))
Countries that DVB-C is available: Germany, Switzerland, Denmark,
Sweden, Norway, Finland, Netherlands
Check the latest information on the available services at the following website. (English only)
http://panasonic.jp/support/global/cs/
Aerial input VHF / UHF
Operating Conditions
Temperature : 0 °C - 35 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 (SCART terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, Q-Link)
AV2 (SCART terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, S-Video in, Q-Link)
AV3
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 :)
AUDIO L - R
RCA PIN Type × 2 0.5 V[rms]
COMPONENT
VIDEO
Y 1.0 V[p-p] (including synchronization)
P
B, PR ±0.35 V[p-p]
Others
HDMI 1 / 2
TYPE A Connectors
HDMI2 : HDMI (Version 1.4 with Audio Return Channel)
This TV supports “HDAVI Control 5” function.
Card slot
SD Card slot × 1
Common Interface slot (complies with CI+) × 1
Output
AUDIO L - R
RCA PIN Type × 2 0.5 V[rms] (high impedance)
DIGITAL
AUDIO OUT
PCM / Dolby Digital / DTS, Fiber optic
Dimensions ( W × H × D )
798 mm × 551 mm × 217 mm (With Pedestal)
798 mm × 511 mm × 93 mm (TV only)
Mass
11.0 kg Net (With Pedestal)
9.5 kg Net (TV only)
Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
This equipment complies with the EMC standards listed below.
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024.
