16
English
AV2 input (COMPONENT / VIDEO)
VIDEO
RCA PIN Type × 1
1.0 V[p-p] (75 :)
AUDIO L - R
RCA PIN Type × 2
0.5 V[rms]
Y
1.0 V[p-p] (including synchronisation)
P
B, PR
±0.35 V[p-p]
HDMI 1 / 2 input
TYPE A Connectors
HDMI1: Content Type
HDMI2: Content Type, Audio Return Channel
Card slot
Common Interface slot (complies with CI Plus) × 1
USB
USB2.0 DC 5 V, Max. 500 mA
DIGITAL AUDIO output
PCM / Dolby Digital / DTS, Fibre optic
Receiving systems / Band name
Check the latest information on the available services at
the following website. (English only)
http://panasonic.net/viera/support
DVB-C
Digital cable services (MPEG2 and MPEG4-
AVC(H.264))
DVB-T
Digital terrestrial services (MPEG2 and MPEG4-
AVC(H.264))
PAL B, G, H, I
SECAM B, G
SECAM L, L’
VHF E2 - E12
VHF A - H (ITALY)
CATV (S01 - S05)
CATV S11 - S20 (U1 - U10)
VHF H1 - H2 (ITALY)
UHF E21 - E69
CATV S1 - S10 (M1 - M10)
CATV S21 - S41 (Hyperband)
Specifications
TV
Model Name
39-inch model
:
TX-39A400E
42-inch model
:
TX-42A400E
50-inch model
:
TX-50A400E
Dimensions (W × H × D)
39-inch model
886 mm × 560 mm × 247 mm (With Pedestal)
886 mm × 516 mm × 53 mm (TV only)
42-inch model
963 mm × 610 mm × 247 mm (With Pedestal)
963 mm × 566 mm × 69 mm (TV only)
50-inch model
1,126 mm × 697 mm × 260 mm (With Pedestal)
1,126 mm × 652 mm × 53 mm (TV only)
Mass
39-inch model
11.0 kg Net (With Pedestal)
10.0 kg Net (TV only)
42-inch model
10.5 kg Net (With Pedestal)
9.0 kg Net (TV only)
50-inch model
16.0 kg Net (With Pedestal)
15.0 kg Net (TV only)
Power source
AC 220-240 V, 50 / 60 Hz
Panel
LED LCD panel
Sound
Speaker output
20 W (10 W + 10 W)
Headphones
M3 (3.5 mm) stereo mini Jack × 1
Connection terminals
AV1 input / output
SCART (Audio/Video in, Audio/Video out, RGB in)
