English
7
● Remove the battery from the unit when not using for
a prolonged period of time to prevent battery leakage,
corrosion and explosion.
LED TV
Declaration of Conformity (DoC)
"Hereby, Panasonic Entertainment & Communication
Co., Ltd. declares that this TV is in compliance with the
essential requirements and other relevant provisions of
the Directive 2014/53/EU."
If you want to get a copy of the original DoC of this TV,
please visit the following website:
https://www.ptc.panasonic.eu/compliance-documents
Authorized Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, D-22525 Hamburg, Germany
5.15 — 5.35 GHz band of wireless LAN is
restricted to indoor operation only in the
following countries.
Austria, Belgium, Bulgaria, Czech Republic, Denmark,
Estonia, France, Germany, Iceland, Italy, Greece, Spain,
Cyprus, Latvia, Liechtenstein, Lithuania, Luxembourg,
Hungary, Malta, Netherlands, Norway, Poland, Portugal,
Romania, Slovenia, Slovakia, Turkey, Finland, Sweden,
Switzerland, Croatia
Maximum radio-frequency power transmitted in the
frequency bands
Type of wireless Frequency band Maximum EIRP
Wireless LAN
2412-2472 MHz 18 dBm
5150-5250 MHz 18 dBm
5725-5850 MHz 13.7 dBm
Bluetooth
®
2402-2480 MHz 7 dBm
Wall mounting the TV (optional)
Please contact your local Panasonic dealer to purchase
the recommended wall-hanging bracket.
a
b
Rear of the TV (View from the side)
Screw for fixing the TV onto the wall-hanging
bracket (not supplied)
Depth of
screw
J Holes for wall-hanging bracket installation
Model a b
32-inch 100 mm 100 mm
J Screw specification
Model Type
Depth of screw
Minimum Maximum
32-inch M4 8 mm 9 mm
Warning
• When optional accessories such as wall brackets etc.
are used, always read and follow the manufacturer
installation and usage instructions.
• Do not mount the unit directly below ceiling lights
(such as spotlights or halogen lights) which typically
give off high heat. Doing so may warp or damage
plastic cabinet parts.
• When installing wall brackets you must ensure the wall
bracket is not electrically grounded to metal wall studs.
Always ensure that there are no electrical cables,
pipes etc. in the wall before you begin the wall bracket
installation.
• To prevent fall and injury, remove the TV from its fixed
wall position when it is no longer in use.
Connecting the TV
• Please ensure the TV is disconnected from the mains
socket/power point before attaching or disconnecting
any RF/AV leads.
• External equipment and cables are for illustrative
purposes only and not supplied with this TV.
• Check the type of terminals and cable plugs are
correct when connecting.
• When using an HDMI cable, use the fully wired one.
• Keep the TV away from electronic equipment (video
equipment, etc.) or equipment with an infrared sensor.
Otherwise, distortion of image/sound may occur or
operation of other equipment may be interfered.
• Also read the manual of the equipment being
connected.
