13
English
Identifying Controls
1 [ ]: Power on/off (Standby)
2 Alexa voice button
≥ Press and hold the button and speak into the
microphone to use voice controls. (p. 14)
3 Select
4D-pad (up/down/left/right navigation buttons)
5Back
≥ Return to the previous place in the menu or app.
6 Home (p. 12)
7Rewind
8 Play/pause
9Volume
10
Guide
11
Mute
12
Settings
≥ Display quick settings for Picture, Screen, Sound,
etc. on the screen.
13
Microphone
14
LED indicator
≥ Lights in different colors when using the remote
control.
15
Menu/Options
16
Fast forward
17
Channel
18
MY APP (Assigns a favorite application.)
19
Streaming Services
1 Remote control signal receiver (for infrared
communication)
≥ Do not place any objects between the TV remote
control signal receiver and remote control.
2 Ambient sensor
≥ Senses ambient lighting conditions to adjust the
picture when [Auto Brightness] and [Auto White
Balance] ( > [Picture] > [Ambient Sensor]) are
set to [On].
3Power LED
≥ The LED blinks when an infrared signal is received
from the remote control.
4 Power button
≥ Press the button to turn on.
≥ When the TV is on, press the button to display the
operation guide.
The item selection switches between Power Off,
Inputs*, Volume Up-Down, Channel Up-Down, and
Exit each time you press the Power button, and
pressing and holding for about 2 seconds enables
item operation.
Press the button to select the input when the input
selection list appears. Press and hold the button to
confirm.
≥ To Power Off (Standby) with the button on the TV
itself, press and hold the Power button for about
2 seconds while Power Off is selected.
≥ To turn Off the apparatus completely, you must pull
the power cord out of the wall outlet.
≥ [ ]: Standby / On (Bottom of the TV)
5 Model name plate
<Note>
≥ The TV consumes a small amount of electric energy
even when turned off.
Remote Control
1
5
4
3
9
6
8
7
12
10
2
11
13
14
15
16
18
19
17
Indicator / Control panel
Red: Standby
Green: On
• Depending on the ambient brightness,
adjusts the brightness of LED to easy-
to-view levels automatically.
Orange: Standby with some functions active
4
1
3
2
5
Bottom of the TV
TV-85W95AP_eng_spa.book 13 ページ ２０２４年６月１２日 水曜日 午前１０時１３分
