24
English
Sound
Speaker output
20 W (10 W + 10 W )
Headphones / Subwoofer
3.5mm stereo mini jack × 1
Channel Capability (Digital)
VHF / UHF: 2 - 69, CATV: 1 - 135
Operating conditions
Temperature
0 °C - 35 °C (32 °F - 95 °F)
Humidity
20 % - 80 % RH (non-condensing)
Connection terminals
HDMI 1 / 2 / 3 / 4 input
TYPE A Connectors
HDMI 1:
HDMI 2 / 3 / 4:
4K60Hz, Channel HDMI 1.4 / 2.0 / 2.1,
eARC (Enhanced Audio Return Channel) /
ARC (Audio Return Channel)
Built-in wireless LAN
Standard compliance and Frequency band
IEEE802.11a/n/ac: 5GHz band
IEEE802.11b/g/n: 2.4GHz band
Security
WPA3-SAE (AES)
WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64bit/128bit)
Bluetooth wireless technology
*
Standard Compliance and Frequency band
Bluetooth
®
5.1: 2.4GHz band
Not all the Bluetooth
®
compatible devices are available
with this TV. Up to 5 devices can be used
simultaneously.
<Note>
Design and Specifications are subject to change without
notice.
Mass and Dimensions shown are approximate.
For the information about the power source and power
consumption, refer to the nameplate on the rear
enclosure.
ETHERNET
10BASE-T / 100BASE-TX
Use Shielded Twist Pair (STP) LAN cable.
USB 1 / 2
USB 1/2 : DC 5V, Max. 500mA [Hi-Speed USB
(USB 2.0)]
DIGITAL AUDIO OUT
PCM / Dolby Audio, Fibre optic
AV IN
Mini, 1.0 V[p-p] (75 )
●
®
●
●
compliant receiver
4K60Hz, Channel HDMI 1.4 / 2.0 / 2.1,
compliant receiver
