English - 8 -
Turning On/Off the TV
Connect power
IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz socket.
After unpacking, allow the TV set to reach the ambient
room temperature before you connect the set to the
mains.
Plug one end (the two-hole plug) of the supplied
detachable power cord into the power cord inlet on
the rear side of the TV as shown above. Then plug
the other end of the power cord into the mains socket
outlet. The TV will switch to standby mode.
Note: The position of the power cord inlet may dier depending
on the model.
To switch on the TV from standby
If the TV is in standby mode the standby LED lights
up. To switch on the TV from standby mode either:
• Press the Standby button on the remote control.
• Press the control button on the TV.
The TV will then switch on.
To switch the TV into standby
• Press the Standby button on the remote control.
• Press the control button on the TV, the function
options menu will be displayed. The focus will be
on the Inputs option. Press the button consecutively
until the Power O option is highlighted. Press and
hold the button for about 2 seconds, the TV will switch
into standby mode.
To switch o the TV
To power down the TV completely, unplug the power
cord from the mains socket.
TV Control & Operation
Your TV has a single control button. This button allows
you to control the Inputs / Volume Up-Down / Channel
Up-Down / Power On-O / Exit functions of the TV.
Note: The position of the control button may dier depending
on the model.
Operating with the Control Button
• Press the control button to display the Power Menu.
• Then press the button consecutively to move the
focus to the desired option if needed.
• Press and hold the button for about 2 seconds to use
the function, enter the sub menu or select the option.
To turn the TV o: Press the control button to display
the Power Menu, the focus will be on the Inputs
option. Press the button consecutively until the Power
O option is highlighted. Press and hold the button for
about 2 seconds to turn the TV o (standby mode).
To turn on the TV: Press the control button, the TV
will turn on.
To change volume: Press the control button to display
the function options menu and then press the button
consecutively to move the focus to Volume Up or
Volume Down option. Press and hold the button to
increase or decrease the volume.
To change channel (in Live TV mode): Press the
control button to display the Power Menu and then
press the button consecutively to move the focus to
Channel Up or Channel Down option. Press and hold
the button to switch to the next or previous channel
in the channel list.
To change input: Press the control button to display
the Power Menu, the focus will be on the Inputs
option. Press and hold the button for about 2 seconds
to display the inputs list. Scroll through the available
input options by pressing the button. Press and hold the
button for about 2 seconds to switch to the highlighted
input option.
Note: Live TV settings menu OSD in Live TV mode cannot be
displayed via the control button.
Operation with the Remote Control
Press and hold the Home button on your remote control
to display available quick settings menu options when
in Live TV mode. Press the Home button to display
