17
English
Specifications
∫ TV
Model No.
: TV-55Z85AP
: TV-65Z85AP
Display Panel
Panel System
OLED panel
Refresh Rate
120 Hz
Screen size
55″ class (54.6 inches measured diagonally)
65″ class (64.5 inches measured diagonally)
W × H × Diagonal
1,210 mm × 680 mm × 1,388 mm (47.6″ × 26.7″ × 54.6″)
1,428 mm × 804 mm × 1,639 mm (56.2″ × 31.6″ × 64.5″)
Number of pixels
3,840 × 2,160
Sound
Speaker output
50 W (15 W × 2 + 20 W × 1)
Headphones / Subwoofer
3.5 mm stereo mini jack × 1
Channel Capability (Digital)
VHF / UHF: 2 - 69, CATV: 1 - 135
Operating conditions
Temperature
0 °C - 35 °C (32 °F - 95 °F)
Humidity
20 % - 80 % RH (non-condensing)
Connection terminals
HDMI 1 / 2 / 3 / 4 input
TYPE A Connectors
HDMI 1:
4K120Hz, VRR (Variable Refresh Rate), NVIDIA
®
G-
SYNC
®
Compatible, AMD FreeSync™ Premium,
Content Type, Deep Color, x.v.Color™
HDMI 2:
4K120Hz, VRR (Variable Refresh Rate), NVIDIA
®
G-
SYNC
®
Compatible, AMD FreeSync™ Premium,
Content Type, eARC (Enhanced Audio Return Channel)
/ ARC (Audio Return Channel), Deep Color, x.v.Color™
HDMI 3 / 4:
4K, Content Type, Deep Color, x.v.Color™
≥ This TV supports “HDAVI Control 5” function.
ETHERNET
10BASE-T / 100BASE-TX
≥ Use Shielded Twist Pair (STP) LAN cable.
USB 1 / 2
USB 1: DC 5 V, Max. 900 mA [SuperSpeed USB
(USB 3.0)]
USB 2: DC 5 V, Max. 500 mA [Hi-Speed USB
(USB 2.0)]
DIGITAL AUDIO OUT
PCM / Dolby Audio, Fibre optic
IR blaster
3.5 mm mini jack × 1
Built-in wireless LAN
Standard compliance and Frequency band
IEEE802.11ax: 6 GHz band
IEEE802.11a/n/ac/ax: 5 GHz band
IEEE802.11b/g/n/ax: 2.4 GHz band
Security
WPA3-SAE (AES)
WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit/128 bit)
Bluetooth
®
wireless technology*
Standard Compliance and Frequency band
Bluetooth
®
5.3: 2.4 GHz band
Not all the Bluetooth
®
compatible devices are available with
this TV. Up to 5 devices can be used simultaneously.
<Note>
≥ Design and Specifications are subject to change without notice.
Mass and Dimensions shown are approximate.
≥ For the information about the power source and power
consumption, refer to the nameplate on the rear enclosure.
≥ For information about the open source software, refer to
[Panasonic eHELP] (Search by Purpose > Read first > Before
use > Licence).
55-inch model
65-inch model
55-inch model
65-inch model
55-inch model
65-inch model
