6
85-inch 500 mm 200 mm
85-inch M8 22 mm 32 mm
Minimum Maximum
When optional accessories such as wall brackets etc.
are used, always read and follow the manufacturer
installation and usage instructions.
Do not mount the unit directly below ceiling lights
(such as spotlights or halogen lights) which typically
give off high heat. Doing so may warp or damage
plastic cabinet parts.
When installing wall brackets you must ensure the
wall bracket is not electrically grounded to metal wall
studs. Always ensure that there are no electrical
cables, pipes etc. in the wall before you begin the
wall bracket installation.
To prevent fall and injury, remove the TV from its
fixed wall position when it is no longer in use.
Please contact your local Panasonic dealer to purchase the
recommended wall-hanging bracket.
Rear of the TV
(View from the side)
Screw for fixing the TV onto the
wall-hanging bracket(not supplied)
Depth of
screw
b
a
Please ensure the TV is disconnected from the
mains socket/ power point before attaching or
disconnecting any RF/ AV leads.
External equipment and cables are for illustrative
purposes only and not supplied with this TV.
Check the type of terminals and cable plugs are
correct when connecting.
When using an HDMI cable, use the fully wired one.
Keep the TV away from electronic equipment (video
equipment, etc.) or equipment with an infrared
sensor. Otherwise, distortion of image/ sound may
occur or operation of other equipment may be
interfered.
Also read the manual of the equipment being
connected.
Rear of the TV
9
SATELLITE cable
RF cable
Aerial
