8
English
Safety Precautions
WARNING
■ Setup
This LCD Display is for use only with the following
optional accessories.
Use with any other type of optional accessories may
cause instability which could result in the possibility
of injury.
Securely install the wall hanging bracket of the
optional accessories. Ask an authorized dealer for
installation.
The following number of people are required for
installation.
98-inch model
86-inch model
75-inch model
:
4 or more
65-inch model
55-inch model
50-inch model
43-inch model
:
2 or more
•
Pedestal
75-inch model
65-inch model
: TY-ST75PE9
55-inch model
: TY-ST55PE9
50-inch model
43-inch model
: TY-ST43PE9
•
Wall hanging bracket
*
1
98-inch model
86-inch model
75-inch model
65-inch model
:
TY-WK98PV1
•
3G-SDI Terminal Board
TY-SB01SS
•
12G-SDI Terminal Board
TY-SB01QS
•
DIGITAL LINK Terminal Board
TY-SB01DL
•
Early Warning Software
(Basic license/3-year license):
ET-SWA100 series
*
2
*
1
:
This product can be purchased in the U.S. and Japan.
*
2
: Suffix of the part number may differ depending on
the license type.
Note
●
The part number of the optional accessories are
subject to change without notice.
●
86-inch model
75-inch model
65-inch model
:
When attaching the wall hanging bracket, be sure to
remove the 2 lower handles.
When installing the wall hanging bracket, read the operating
instructions supplied with it carefully and install properly.
Also, always use the overturn prevention accessories.
We are not responsible for any product damage, etc.
caused by failures in the installation environment for
the pedestal or wall hanging bracket even during the
warranty period.
Small parts can present choking hazard if accidentally
swallowed. Keep small parts away from young children.
Discard unneeded small parts and other objects,
including packaging materials and plastic bags/sheets to
prevent them from being played with by young children,
creating the potential risk of suffocation.
Do not place the Display on sloped or unstable
surfaces, and ensure that the Display does not hang
over the edge of the base.
•
The Display may fall off or tip over.
Install this unit at a location with minimal vibration
and which can support the weight of the unit.
•
Dropping or falling of the unit may cause injury or
malfunction.
Caution - For use only with UL Listed Wall Mount
Bracket with minimum weight/load 70.0
(154.33 lbs).
98-inch model
:
When installing the display vertically, be sure that
the power indicator comes to the right side.
Power indicator
86-inch model
75-inch model
65-inch model
55-inch model
50-inch model
43-inch model
:
When installing the display vertically, be sure that
the power indicator comes to the upper side.
Power indicator
•
If installed in different directions, heat is generated
and it may cause fire or damage to the Display.
When using this unit, be sure to take safety
measures to prevent falling or dropping of the unit.
•
If an earthquake occurs or a child climbs the unit, the
unit may fall or drop, resulting in an injury.
Do not position the unit with its liquid crystal panel
facing upright.
•
There are conditions of mounting method,
environmental temperature, connections and settings.
If installed in different conditions, heat is generated
and it may cause fire or damage to the Display.
