40
English
RECALL
It is possible to check the setting status of input label,
picture mode, etc.
Press <RECALL>.
Current setting status will be displayed.
10:00
1
2
7
8
3
4
5
6
HDMI1
Full
AUDIO IN
Memory name: MEMORY2
Schedule play mode
Off timer
90 min
Backup mode OK
1 Input label
2 Aspect mode (see page 42)
3 Backup input change (see page 62)
4 Audio input (see page 67)
5 Profile name (see page 54)
6 [Schedule play mode] (see page 136)
7 Off timer remaining time (see page 41)
8 Clock / Mute (see page 40, 77)
●
When there is no video signal to the selected input,
[No signal] is displayed for about 30 seconds at the
end.
●
When a USB memory is not connected to the USB
terminal at the time of switching to the USB input, [No
external media] is displayed for about 30 seconds.
Even when a USB memory is connected, if it does not
contain any playable file, [No play file] is displayed at
all times.
●
When [No signal image settings] - [Display setting] is
set to [On] (see page 70), the message [No signal] /
[No external media] / [No play file] are not displayed.
Instead, the image set in [No signal image settings]
will be displayed.
●
To display the clock, set [Date and time] and then set
[Clock display] to [On]. (see page 77)
Volume Adjustment
Press <VOL +> <VOL -> or <+ (Unit)> <- (Unit)> to
adjust volume.
Unit
INPUT ENTERMENU
+
-
20
Volume (INTERNAL SPEAKERS)
●
The current sound volume level is memorised even if
the power is turned off.
●
When [Maximum VOL function] is set to [On], the
volume can only be adjusted to the maximum point
you set, and the displayed value turns red when it
reached its maximum. (see page 99)
●
When [Initial VOL function] is set to [On], the volume
will be at the set level when the display is turned on.
(see page 59)
Sound mute On / Off
It is useful when you want to mute the sound temporarily,
for example, when answering the phone or door.
Press <MUTE>.
●
appears on the screen and the sound is muted.
Press again to reactivate the sound.
●
It is also reactivated when the power is turned on / off
or the volume level is changed.
●
While MUTE is active,
is displayed as a reminder
after operation.
●
When the image set in [No signal image settings]
(see page 70) is displayed,
is not displayed after
operation.
●
In [ENGLISH(US)] OSD language,
is displayed as
[MUTE].
