20
English
Eyebolt
98-inch model
86-inch model
75-inch model
The display has holes for attaching eyebolts (M10).
When installing, use them to suspend the display.
Use the eyebolt only for temporary suspension or
movement for installation. This cannot be used for
permanent hanging installation.
Note
●
The 98/86/75-inch models have the holes for
attaching eyebolts. 65/55/50/43-inch models don’t.
98-inch model
Eyebolt (commercially available) mounting positions
86-inch model
75-inch model
Eyebolt (commercially available) mounting positions
Attaching the eyebolts
98-inch model
1
Remove the bolt and nut from the
eyebolt mounting position (two
locations).
Bolt
Nut
2
Attach the eyebolt and nut on the
mounting position (two locations).
Eyebolt
Nut
3
After removing the eyebolt, attach the
bolt and nut.
Bolt
Nut
