9
English
Installing the TV
A Pedestal (2)
B Assembly screw (4)
Take out the pedestal and the TV from the packing case
and put the TV onto a work table with the screen panel
down on the clean and soft cloth (blanket, etc.).
≥ Use a flat and firm table bigger than the TV.
≥ Do not hold the screen panel part.
≥ Make sure not to scratch or break the TV.
≥ Insert the pedestal firmly, otherwise it may come off
when setting up the TV.
≥ Do not assemble the pedestal by any method other
than those specified below.
Be sure to remove the pedestal in the following
procedures when you use the wall-hanging bracket or
repack the TV.
1 Put the TV onto a work table with the screen panel
down on the clean and soft cloth.
2 Remove the assembly screws B from the pedestal.
3 Pull out the pedestal from the TV.
M4 × 20 (mm)
M4 × 24 (mm)
Preparations
40-inch model
50-inch model 58-inch model
65-inch model
Assembling the pedestal
Removing the pedestal
A
B
TH-40_50_58_65JX700GKST_Eng_8A06B00034100.book 9 ページ ２０２１年２月１９日 金曜日 午後４時５３分
