Specifications
Interface ports
RGB2 input terminal
Video input terminal
S-Video input terminal
Serial input/output terminal
Remote1 input/output terminal
Remote2 input terminal
DVI-D input terminal
LAN terminal
1 set of high-density, D-Sub 15-pin (female)
[For YPBPR input]
Y: 1.0 V [p-p] synchronization signal included, PBPR: 0.7 V[p-p] 75 Ω
[For RGB input] 0.7 V[p-p] 75 Ω For G-SYNC: 1.0 V[p-p] 75 Ω
HD/SYNC: TTL, high-impedance, positive/negative polarity
automatically adjusted
VD:
TTL, high-impedance, positive/negative polarity automatically adjusted
•
HD/SYNC, VD terminals are not compliant with 3 value composite SYNC.
1 set BNC
1.0 V[p-p] 75 Ω
1 set Mini DIN 4-pin
Y 1.0 V[p-p] C 0.286 V[p-p] 75 Ω Compliant with S1 signals
1 set each for D-Sub 9-pin (male/female), RS-232C compliant
Used for personal computer control
1 set each for M3 stereo mini jack
Wired remote control, used for link control
1 set D-Sub 9-pin (female)
Used for external control
1 set DVI-D 24-pin Single link, compatible with HDCP
1 set RJ-45 Compliant with PJLink
TM
Length of power cord
3.0 m
Cabinet
Molded resin
Outside dimensions
Width: 530 mm; Height : 167 mm; Depth: 425 mm
Mass
13.9 k 13.1 k 13.9 k 13.1 k
Working environment condition Ambient temperature*
4
: 0 °C to 45 °C
Ambient humidity : 20 % to 80 % (no condensation)
Remote control
Power source
Operation range
Mass
Outside dimensions
3 V DC (two AA dry cells)
approx. 30 m (in front of beam receiver)
134 (including dry cells)
Width: 51 mm, Thickness: 23 mm, Depth: 176 mm
Option
Hanging attachment
(For high ceiling)
Hanging attachment
(For low ceiling)
Projection lens
Replacement lamp unit
ET-PKD56H
ET-PKD55S
PT-D5700E/PT-D5700EL
ET-DLE100, ET-DLE200, ET-DLE300, ET-DLE400, ET-DLE050
PT-DW5100E/PT-DW5100EL
ET-DLE100, ET-DLE200, ET-DLE310, ET-DLE410, ET-DLE050
ET-LAD57 (single bulb), ET-LAD57W (double bulbs)
• The outside dimensions do not include the lens and other protruding parts. See page 62 for further details.
*
4
When using the projector at high altitudes (1 400 to 2 700 m), the upper limit for the ambient temperature drops
by 5 °C.
PT-D5700E PT-D5700EL PT-DW5100E
PT-DW5100EL
Model No.
