6
The position you select for the refrigerator installation should be well-ventilated and has less hot air. Do not locate the
refrigerator near a heat source such as cooker, boiler, and avoid it from direct sunlight, thus guaranteeing the refrigeration
effect while saving energy consumption. Do not locate the refrigerator in the damp place, so as to prevent the refrigerator
from rusting and leaking electricity. The result of the refrigerant charge amount of the refrigerator being divided by
the total space of the room in which the refrigerator is installed shall be less than 8g / m³.
Note: The amount of refrigerant charged for the refrigerator can be found on the nameplate.
2. Heat dissipation space
When working, the refrigerator gives off heat to surroundings. Therefore, at least 30mm of free space should be spared
at the top side, more t
han 100mm on both side s, and above 50mm at the back side of the refrigerator.
Dimensions in mm
WD H A B
C(°)
EF
750 785 1680 1280 1490
130±5
50 100
Note：Figure 1, Figure 2 only illustrate the space demand of the product.
Level gro
und
Place the refrigerator on the so
lid and flat ground (floor) to keep it stabl e, or else, it will give rise to vibration and noise.
When the refrigera tor i s pla ced on such flo oring mat erials as carpet, stra w ma t, poly viny l chl oride, the soli d backing plates
should be applied underneath the refrigerator, so as to prevent color change due to heat dissipation.
Unobstructed ventilation shall be maintained around the appliance or in an embedded structure.
Preparations for use
1. Standing time
After the refrigerator is properly installed and well cleaned, do not switch it on immediately. Make sure to energize the
refrigerator after more than 1 hour of standing, so as to ensure its normal operation.
2. Cleaning
Confirm the accessory parts inside the refrigerator and wipe the inside with a soft cloth.
3. Power-on
Insert the plug into the solid socket to start the compressor. After 1 hour, open the freezer door, if the temperature inside
the freezer compartment drops obviously, it indicates the refrigeration system is working normally.
4. Storage of food
After the refrigerator runs for a period of time, the internal temperature of the refrigerator will be automatically controlled
according to the user’s temperature setting. After the refrigerator is fully cooled, put in foods, which usually need 2~3
hours to be fully cooled. In summer, when the temperature is high, it takes more than 4 hours for the foods to be fully
cooled (Try to open the refrigerator door as less a s possible before the internal temperature cools down).
If the refrigerator is installed in the moisture place, make sure to check whether the ground wire and leakage circuit
breaker are normal. If vibration noises are produced due to the refrigerator contacting the wall or if the wall gets blackened
by air convection around the compressor, move the refrigerator away from the wall. Setting up the refrigerator may cause
jamming noise or image chaos to the mobile phone, fixed-line telephone, radio receiver, television set surrounding it, so
try to keep the refrigerator as far away as possible in such case.
Functions
1.1 temperature setting
Press the Temp button to adjust the temperature. After the temperature is adjusted to the expected gear, the setting will
take effect if no more key operation is performed within 5 seconds, and the corresponding gear will be operated
immediately. Temperature gear setting cycle sequence: "5-4-2-8-6-5"
1.2 fast cooling
1）As the fridge chamber cools quickly, so does the temperature of the freezer to ensure that the food is well preserved
with nutrition and good taste. Quick cooling function can be maintained for up to 30 hours. After that, it will automatically
exit and the temperature gear will return to the setting before the quick-cooling feature was enabled.
