7
Location of Controls
1 External Air Vent
2 Internal Air Vent
3 Door Safety Lock System
4 Exhaust Air Vent
5 Control Panel
6 Identification Plate
7 Glass Tray
8 Roller Ring
9 Heat/Vapor Barrier Film
(do not remove)
10 Waveguide Cover
(do not remove)
11 Door Release Button
12 Warning label
13 Menu label
14 Power Supply Cord
15 Power Supply Plug
16 Warning label
17 Door hinges
To prevent injury when opening
or closing the door, keep fingers
away from the door hinges.
18 Display Window
19 Popcorn Pad (See page 12)
20 Sensor Reheat Pad
(See page 14)
21 Sensor Cook Pad (See page 14)
22 Inverter Turbo Defrost Pad
(See page 13)
23 Power level Pad (See page 10)
24 Keep Warm Pad (See page 12)
25 Quick 30 Pad (See page 12)
26 Number Pads
“0” pad: also acts as door open
pad (See page 9)
27 More Pad (See page 12, 14)
28 Less Pad (See page 12, 14)
29 Cooking Timer Pad
(See page 9, 10, 11)
30 Clock Set Pad (See page 8)
31 Stop/Reset Pad
Before cooking: One tap clears
all your instructions. During
cooking: one tap temporarily
stops the cooking process.
Another tap cancels all your
instructions, and time of day
or colon appears in the display
window.
32 Start Pad
After cooking program setting,
one tap allows oven to begin
functioning. If door is opened or
Stop/Reset Pad is pressed once
during oven operation, Start
Pad must be pressed again to
restart oven.
Beep Sound:
When a pad is pressed correctly, a
beep will be heard. If a pad is pressed
and no beep is heard, the unit did
not or cannot accept the instruction.
When operating, the oven will beep
twice between programmed stages.
At the end of any complete program,
the oven will beep 5 times.
NOTE:
If no operation after cooking
program setting, 6 minutes later, the
oven will automatically cancel the
cooking program. The display will
return to clock or colon display.
NOTE:
The illustration is for reference only.
18
19
20
23
25
26
29
31
22
21
27
28
24
30
32
16
613 1617
4
212 10 14
15
9
3
5
11
7
8
* The control panels of NN-SN686S/NN-SN67HS/NN-SN65HS
have same key layout and function, even the different key
name.
