GB8
Control Panel Instructions
,&&18"3.
It has an automatic menu with a "heating" process, and automatically enters the heat
preservation mode when the temperature reaches a fixed value. In the keep warm state, the
display shows the “ ” symbol and enters the keep warm countdown for four hours.
● In the keep warm mode, the temperature will be maintained at about 55°C, the speed at
PL (intermittent stirring), and the keep warm time will be about 4 hours.
● For the hot liquid of the automatic menu, it will automatically enter the keep warm mode
after the process ends. (The keep warm mode of SOUP (CHUNKY) and SAUCE (PASTA)
will not include the speed at PL (intermittent stirring).)
$-&"/
It combines heat and high power blending to remove residues from the jug.
① After adding 1000 mL of fresh water (adjust the water amount as necessary), turn the
knob to access the cleaning mode and press the “ ” button to initiate the cleaning
process in standby mode.
● The cleaning mode time is fixed at 10 minutes, and it will preheat while stirring (dynamic
cycle). (The actual time will differ from the displayed time due to different water
temperature or water volume). After the preheating is completed, the countdown will be
displayed for 3 minutes.
● If the “ ” button is not pressed within 5 minutes during the setting process, the
screen will return to the initial screen.
② When entering the self-cleaning mode, it will stir and preheat at the same time (dynamic
cycle). The countdown will not start until the preheating is completed.
● The “ ” symbol flashes during heating and the “ ” symbol stays on when the
heating process stops.
● The “ ” symbol flashes during blending and the blending gear remains on.
When the blending process comes to a stop, the “ ” symbol stays on, and the
blending gear goes out.
③ The buzzing sound is heard when the cleaning process is complete.
● Make sure that the maximum water amount does not exceed approximately 1200 mL.
If there are food residues, adjust the amount of water accordingly.
● Make sure that the minimum water amount is approximately 400 mL to prevent the
blades from running idle, which could lead to malfunctions or accidents.
● When the “CLEAN” function is running, the appliance heats up. Therefore, be careful
with the residual heat during and after cleaning.
① When on standby, select the menu that can be reserved with turn the knob.
Press the “ ” button to access the “Reserve Mode” for the selected menu.
② Adjust the reservation completion time by rotating the knob.
● Adjustable time range: --:-- , 02:00 - 12:00 hours (the program can cycle through the
options).
● “--:--” is the non-reservation mode. Press the “ ” button to skip the reservation and
start production directly.
● Adjustable by 30 minutes at a time.
● The initial reservation time is set for 2 hours.
● If no adjustments are made within 5 minutes during the setup process or if the “ ”
button is pressed, the program returns to the initial screen.
③ Press the “ ” button to start working.
● The scheduled time is the completion time, which is dependent on various factors such
as the quantity of ingredients and the environment.
Every detail in this Operating Instructions has been thoroughly examined. However, if you come across any
typographical errors or ambiguities, consult with us for clarification.
Note: Texts and images highlighted with background colors provide supplementary information.
Any technical improvements to the appliance will be incorporated in the updated version of the Operating
Instructions without any prior notice.
Note that the appearance and color of the appliance may be subject to changes.
Please refer to the actual item.
