Pressure Sensor Lineup

Higher precision, more advanced function

Dual Display Digital Pressure Sensor

For gas

DP-100 SERIES Ver.2

• Dual-screen 3-color display

(red, green, orange) for added

ease of operation.

• Wide variation of pressure ports.

• Provided with 2 outputs

(standard type).

• Provided with analog output or

external input (multi-function

type).

• Provided with copy function for

reduced man-hours and

human error.

• Oil-free type also available for

prevention of entry of oil or

grease in air pipes.

• Compound pressure types (for

low pressure / for high

pressure) are available.

Installation on a panel or moving part possible

Head-separated Dual Display Digital Pressure Sensor

For gas

DPC-100 SERIES DPH-100 SERIES

• High response speed of

500 μs.

• Automatic recognition of

sensor head without initial

setting.

• Sensor head can be installed

easily using an Allen wrench.

• Standalone use of sensor

head is possible.

• Provided with 2 outputs

(analog voltage and current).

• Compound pressure type,

positive pressure type and

negative pressure type are

available.

Detection of liquid pressure

Head-separated Dual display Digital Pressure Sensor

For gas & liquid

DPC-L100 SERIES DPH-L100 SERIES

• High-precision liquid / air

pressure detection and

excellent operability.

• Compact stainless steel body

withstands pressure of up to

50 MPa.

• Oil-less, single diaphragm

structure.

• Mounted with throttle to

achieve high resistance to

pressure surge.

• Standalone use of sensor

head is possible.

• Provided with 2 outputs

(analog voltage and current).

• Compound pressure type and

positive pressure type are

available.

Multi-unit connection and network communication supported

Head-separated Dual Display Digital Pressure Sensor

For gas

DPS-400 SERIES DPH-100 SERIES

• Ultra-high response speed of

150 μs.

• Network communication is

possible.

• Allows connection of up to 16

units and copying of settings.

• One-touch cable for reduced

wiring work.

• Sensor head can be installed

easily using an Allen wrench.

• Standalone use of sensor

head is possible.

• Provided with 2 outputs

• Compound pressure type,

positive pressure type and

negative pressure type are

available.

Certification

[DP-101 (A) / 102 (A) only]

Conforming to

EMC Directive

Conforming to

EMC Directive

Conforming to

EMC Directive

Certification of

Recognition

Conforming to

EMC Directive

Certification of

Recognition
