Electrical Connections (continued)
❐ Advanced system configuration
CY-VMD9000U
Control unit (front)
Video (Yellow)
Video (Yellow)
Video (Yellow)
Video (Yellow)
L (White)
L (White)
L (White)
L (White)
VTR1-IN
RCA cord (optional)
RCA cord (optional)
CY-VMD9000U
Display unit (rear)
Display unit/control unit connecting cord
(supplied to CY-VMD9000U)
R (Red)
R (Red)
R (Red)
R (Red)
CY-VMX6800U
VTR2-IN
Game player (optional)
Power connector
2
VIDEO-OUT
Display unit1
Display unit
1
Example combination
≥ DVD player (CX-DV700U)
≥ Game player
CX-DV700U DVD player
RCA cord (optional)
RCA cord (optional)
VIDEO-OUT
REMOTE-IN
Video (Yellow)
VTR1-IN
REMOTE-OUT
R (Red)
CY-VMX6800U
L (White)
VTR2-IN
AUDIO-OUT
Game player (optional)
Power connector
2
Video (Yellow)
L (White)
R (Red)
Video (Yellow)
L (White)
R (Red)
Display unit
1
R (Red)
L (White)
Video (Yellow)
❐ Basic system configuration
Example combination
≥ In-dash 7 wide color LCD monitor/DVD-video, CD player (CY-VMD9000U)
≥ Game player
Notes:
≥ “REMOTE-OUT” is exclusively used for VTR1.
≥ Be sure to fully plug in the connector.
≥ When game devices are connected, the image may be unstable.
≥ Refer to the operating instructions for the connected devices, in addition.
Notes:
≥ Be sure to fully plug in the connector.
≥ When game devices are connected, the image may be unstable.
≥ Refer to the operating instructions for the connected devices, in addition.
