25
CQ-DFX301N
20
E
N
G
L
I
S
H
General
FM Stereo Radio
Specifications
Frequency Range : 87.5 - 108 MHz
Usable Sensitivity : 6 dB/µV(S/N 30 dB)
Stereo Separation : 35 dB (at 1 kHz)
Frequency Range : 531 - 1,602 kHz
Usable Sensitivity : 28 dB/µV (S/N 20 dB)
Frequency Range : 153 - 279 kHz
Usable Sensitivity : 32 dB/µV (S/N 20 dB)
Sampling Frequency : 8 times oversampling
DA Converter : MASH•1 bit/4 DAC System
Error Correction System : Panasonic Super Decoding
Algorithm
Pick-Up Type : Astigma 3-beam
Light Source : Semiconductor laser
Wavelength : 780 nm
Frequency Response : 20 Hz - 20 kHz (±1 dB)
Signal to Noise Ratio : 96 dB
Total Harmonic Distortion : 0.01 % (1 kHz)
Wow and Flutter : Below measurable limits
Channel Separation : 75 dB
CD Player
LW Radio
MW Radio
Power Supply : DC 12 V (11 V - 16 V), Test
Voltage 14.4 V, Negative
Ground
Tone Controls : Bass; ±12 dB at 100 Hz
Treble;±12 dB at 10 kHz
Current Consumption : Less than 2.5 A (CD mode,
0.5 W 4-Speaker)
Maximum Power Output : 45 W x 4 (at 4 Ω)
Power Output : 22 W x 4
(DIN45 324, at 4 Ω)
Speaker Impedance : 4 - 8 Ω
Pre-Amp Output Voltage : 2 V (CD mode)
Pre-Amp Output Impedance : 600 Ω
Dimensions (Main Unit) : 178(W) x 50(H) x
150(D) mm
Weight (Main Unit) : 1.6 kg
Note: Specifications and design are subject to modification without notice due to improvements.
