99
Input/output signal settings
Setting the material names
Material names can be given to the input signals.
These names can be selected from the default settings or
user settings.
1On the Input sub menu, use [F2] to select the input to
be set using the Select item.
Refer to “Input signal settings”.
2Use [F1] to display the Name sub menu.
3Use [F2] to select the type of material names using the
Type item.
Default
(default
settings)
Select the material names from the following:
IN1, IN2, 12G SDI IN3 to 8, IN-A1 to 4,
IN-B1 to 4
User
(user
settings)
The material names are set using up to 32
characters.
Setting the up-converter
Select the settings for SDI IN5 to SDI IN8, as well as for the
up-converter that is built into the optional unit listed below:
p AV-UHS5M1 (SDI Input Unit)
1On the Input sub menu, use [F2] to select the input to
be set using the Select item.
Refer to “Input signal settings”.
2Use [F1] to display the Up/Down Converter sub menu.
3Use [F2] to set the image movement detection
sensitivity using the Move Detect item.
1 Toward still images
3 Standard
5 Toward moving images
4Use [F3] to set the extent of the edge sharpness for the
images using the Sharp item.
1 Not sharp edges
3 Standard
5 Very sharp edges
