94
Input/output signal settings
Input signal settings
IN1 and IN2 are exclusive input by SDI signals or HDMI signals.
SDI IN3 to 8 are SDI signal inputs.
IN-A1 to 4, IN-B1 to 4 can be set only when one of the following optional units has been connected.
AV-UHS5M1 (SDI Input Unit) IN-A1 to A4 and IN-B1 to B4 can be set.
AV-UHS5M3 (HDMI Input Unit) IN-A1 to A3 and IN-B1 to B3 can be set.
Before setting the input signals, first select the input signal to be set using the Input sub menu.
1Press the
IN
OUT
button to light its indicator, and display the Input menu.
2Use [F1] to display the Input sub menu.
3Use [F2] to select the input signals using the Select item.
The menu display is switched in accordance with the input signals which have been selected.
The menu title is set to “MENU: Input (signal type)/input connector (material name)”.
Signal type SDI, HDMI
Material name Material name set in “Setting the material names”.
<Example of menu (SDI)>
