104
Input/output signal settings
Displaying the HDMI input signal information
These are used to display the information concerning the HDMI input signal images.
The information cannot be changed.
1On the Input sub menu, use [F2] to select the input to be set using the Select item.
Refer to “Input signal settings”.
2Use [F1] to display the HDMI Status sub menu.
Size This indicates the pixel count of the images.
Dot Clock This indicates the dot clock frequency of the images.
H-Frequency This indicates the horizontal frequency of the images.
V-Frequency This indicates the vertical frequency of the images.
The formats supported are listed below.
<HDMI formats supported>
HDMI input signal
Dot clock
frequency
(MHz)
Frequency
Horizontal
(kHz)
Vertical
(Hz)
XGA 1024×768
Digital
65.0 48.36 60.00
WXGA 1280×768
Digital
79.5 47.78 59.87
SXGA 1280×1024
Digital
108.0 63.98 60.02
WSXGA+ 1680×1050
Digital
146.2 65.29 59.95
UXGA 1600×1200
Digital
162.0 75.00 60.00
WUXGA 1920×1200
Digital
154.0 74.04 59.95
WQHD 2560×1440
Digital
241.5 88.79 59.95
720/59.94p 1920×1080
Digital
74.25/1.001 44.96 60.00/1.001
720/50p 1920×1080
Digital
74.25 37.50 50.00
1080/59.94i 1920×1080
Digital
74.25/1.001 33.72 60.00/1.001
1080/50i 1920×1080
Digital
74.25 28.13 50.00
1080/23.98p 1920×1080
Digital
74.2 27.0 24.00
1080/24p 1920×1080
Digital
74.2 27.0 24.00
1080/25p 1920×1080
Digital
74.2 28.1 25.00
1080/29.97p 1920×1080
Digital
74.2 33.7 30.00
1080/59.94p 1920×1080
Digital
148.5/1.001 67.50/1.001 60.00/1.001
1080/50p 1920×1080
Digital
148.5 56.25 50.00
2160/59.94p 3840×2160
Digital
594.0/1.001 134.9 60.00/1.001
2160/50p 3840×2160
Digital
594.0 112.5 50.00
If the format of the input signals is not supported, it may not be possible to import the signals properly, and a black image or
disturbed image may appear.
