101
Input/output signal settings
6Use [F1] to display the C/C Tone2 Gray L sub menu.
7Use [F2] to adjust the R signal of the Gray Low level in
the Red item.
8Use [F3] to adjust the G signal of the Gray Low level in
the Green item.
9Use [F4] to adjust the B signal of the Gray Low level in
the Blue item.
Use [F1] to display the C/C Tone3 Gray H sub menu.
Use [F2] to adjust the Gray High level of the R signal in
the Red item.
Use [F3] to adjust the Gray High level of the G signal in
the Green item.
Use [F4] to adjust the Gray High level of the B signal in
the Blue item.
> Use [F1] to display the C/C Tone4 White sub menu.
Use [F2] to adjust the R signal of the white level in the
Red item.
Use [F3] to adjust the G signal of the white level in the
Green item.
Use [F4] to adjust the B signal of the white level in the
Blue item.
The unit joins the set black level, gray Low level, gray
High level, and white level with a simplified curve to
create a tone curve. The desired tone curve may not be
achieved, depending on the setting values.
Note
Gain adjustments for the color matrix
1Use [F1] to display the C/C Matrix R/G sub menu.
2Use [F2] to set the gain value of the R-G axial direction
in the R-G item.
3Use [F3] to set the gain value of the R-B axial direction
in the R-B item.
4Use [F4] to set the gain value of the G-R axial direction
in the G-R item.
5Use [F5] to set the gain value of the G-B axial direction
in the G-B item.
6Use [F1] to display the C/C Matrix B sub menu.
7Use [F2] to set the gain value of the B-R axial direction
in the B-R item.
8Use [F3] to set the gain value of the B-G axial direction
in the B-G item.
