2.4 Technical data

2.5 ErP data - Technical Data Sheet

2. PRODUCT DESCRIPTION

2.1 Product identification

Identification details can be found on the type

plate fixed to the product. It contains product

information and other useful data.

The product is designed and manufactured in

accordance with:

• Safety standard EN 60335-1

• Safety standard EN 60335-2-21

• Welding standard EN ISO 3834-2

• Pressure vessel standard EN 12897

2.2 Intended use

The product is designed to supply domestic

hot water in combination with a central heat-

ing and cooling system. The product has been

designed to be connected to an external heat

pump.

2.3 CE marking

The CE mark shows that the product complies

with the relevant Directives. See Declaration of

Conformity at the manufacturers’ website for

more information.

The product complies with EU directives:

• Low voltage LVD 2014/35/EU

• Electromagnetic compatibility EMC 2014/30/EU

• Pressurised equipment PED 2014/68/EU

Any safety valve(s) used in the system shall be

CE-marked and comply with PED 2014/68/EU.

Parameter Unit Description

Measures HxWxD mm 1751x599x646

Weight (empty) kg 111

Weight (full) kg 401

Volume litres DHW+Buffer 230+60

Electric element - effect kW 2.8

Power supply V / Phase / Hz 230 / 1 / 50

Domestic hot water tank:

Volume litres 230

Max working pressure MPa (bar) 1,0 (10)

Pressure test (bar) MPa (bar) 1,5 (15)

Max working temp ºC 80

Connections / Material mm / EN ø22 / 1.4404

Tank material EN 1.4521

Insulation Material/thickness PUR / 50

Heating coil surface m² 1.8

Energy loss at 65ºC kWh/24h 1,25 / 0,7

Buffer tank:

Volume litres 60

Max working pressure MPa (bar) 0,3 (3,0)

Pressure test MPa (bar) 0,39 (3.9)

Max working temp ºC 80

Connections / Material mm / EN Ø22, copper

Tank material EN 1.4521

Insulation Material/thickness PUR / 50

Directive: 2010/30/EU Regulation: EU 812/2013 Directive: 2009/125/EC Regulation: EU 814/2013

Heat loss tested according to standard: EN 12897:2016

Brand Model name

ErP rating

DHW tank

ErP rating

buffer tank

Standing heat

loss DHW tank

Standing heat

loss buffer tank

Storage vol. ltr.

DHW tank

Storage vol. ltr.

buffer tank

OSO PAW-TD23B6E5

B

A 52 29

230

60
