6

www.panamax.com

VT1512-IP Instruction Manual - English

Example 2:

Query Command Message with xid –

<?xml version=”1.0” ?><device class=”vt1512” id=”1065a3050000”>

<command xid=”456”><sendinfo/></command></device>

Response Message with ack –

<?xml version=”1.0” ?><device class=”vt1512” id=”1065a3050000”>

<info>…</info><ack xid=”456”></device>

3. Event Messages

Event messages are sent when a change of device status or settings occurs. The <event> element is used to contain the details of the event. Note that events are not sent in reply to a

query command.

Example Event Message - outlet 3 switched to ON:

<?xml version=”1.0” ?>

<device class=”vt1512” id=”1065a3050000”>

<event time=”1403729752” evtid=”123” subsid=”1”>

<outlet id=”3”>1</outlet>

</event>

</device>

Element Description

dlys required delays container.

dly outlet delays - attributes represent: “id” = outlet number, “sf” = power sequence off delay, “so” = power sequence on delay,

“cy” = power cycle delay. All delays values are in seconds, 255 seconds maximum.

grps required groups container.

sq opt-in/opt-out of sequence group: hexadecimal value represents which outlet participate in power sequence group. See above for details.

cy opt-in/opt-out of power cycle group: hexadecimal value represents which outlet participate in power cycle group. See above for details.

Outlet number Outlet group hex code Binary

1 through 12 (i.e., all twelve outlets) fff 1111 1111 1111

1, 3, 6 and 7 (i.e., four outlets) 065 0000 0110 0101

Settings-related messages (i.e., <sendsettings> query, <set> action, and <set> event) contain the same content fragment format:

Details –

Outlet Hex Binary

1 001 0000 0000 0001

2 002 0000 0000 0010

3 004 0000 0000 0100

4 008 0000 0000 1000

5 010 0000 0001 0000

6 020 0000 0010 0000

7 040 0000 0100 0000

8 080 0000 1000 0000

9 100 0001 0000 0000

10 200 0010 0000 0000

11 400 0100 0000 0000

12 800 1000 0000 0000
