13
USER MANUAL
Product number PVILS
Product type Line isolator
No. of channels 1
Type passive
Transformer isolated Yes
No. of inputs 2
Input type unbalanced
Input connections Cinch
No. of outputs 1
Output type balanced
Output connections XLR
Ground/lift switch Yes
Housing Aluminium continuous casting
Dimensions (H/W/D) 140 x 50 x 68 mm
Weight 0.385 kg
Ambient temperature for operation -20°C…70°C
Relative air humidity <80%, non-condensing
Included accessories Rubber feet, label (tour label)
AUDIO
Max. input level (<1% THD, 20 Hz) +12 dBu
Max. input level (< 1% THD, 1 kHz) +32 dBu
Frequency response (±0.2 dB, relative 1 kHz) 20 Hz-30 kHz
Input impedance (1 kHz) 2.7 kΩ
Output impedance (1 kHz) 600 Ω
THD (30 Hz, +4 dBu, unity, unweighted) < 0.08%
THD (1 kHz, +4 dBu, unity, unweighted) < 0.003%
IMD (SMPTE) (60 Hz/7 kHz, 4:1, +4 dBu) < 0.002%
Transformer ratio 1:1
All measurements were taken with a generator with 600Ω output impedance (incl. open inputs) and 1kΩ
balanced load.
TECHNICAL DATA
GENERAL
EN
