EN ENDE ES
8
TECHNICAL SPECIFICATIONS
DI Box active
Product Type: DI box
Type: active
Number of Channels: 1
Number of Inputs: 2
Input Connections: 6.3 mm mono jack (TS jack), XLR/f unbalanced, PIN 1 & 3 bridged.
Max. Input Level: 45 dBu
Input Impedance: 0 dB & 12 dB: 1 MOhm; -10 & -20 dB: 70 kOhm; -30 dB: 40 kOhms
Input Attenuation: 0 dB, -10 dB, -20 dB, -30 dB
Signal Gain: +12 dB
Number of Outputs: 1
Number of THRU Outputs per
Channel:
1
Output Connections: XLR/f balanced, 6.3 mm jack
Maximum Output Voltage: 15 dBu @ 1 kOhm load with phantom power; 19.7 dBu @ 1 kOhm;
> 20 dBu @ 10 kOhms at 9 V battery
Output Impedance: 600 ohms
Frequency Response: 20 Hz - 20,000 Hz
Transformer-balanced: yes
Translation Ratio (Ratio): 3.16:1, 10:1, 31.6:1, 1:4
Controls: Ground-Lift, Attenuator, Boost, 9 VBat/+48 V/Power Off
Power Supply: 9 V block battery, + 48 V phantom power
Power Consumption: at 0 dBu @ 600 ohms: approx 4 mA/48 V or 18 mA / 9 V
Housing Material: sheet steel
Housing Surface: powder coated
Width: 116 mm
Depth: 140 mm
Height: 43.5 mm
Weight: 0.85 kg
