8
3. Charging
3.6 Gold Mount MPL batteries can be linked to Gold Mount PAGlink
batteries Models 9306 & 9313 for charging. It is not possible to
link V-Mount MPL batteries with V-Mount PAGlink batteries,
because the linking contacts are located in different positions.
3.7 Each PL16 charging position receives the same current and
faster charge times can be achieved by spreading batteries
evenly across both channels. Batteries that have a similar state-
of-charge should also be stacked together for the most efficient
use of power. Connecting only one battery to the charger ensures
that it will receive all the current, and charge in the quickest
possible time.
3.8 Charge Times: From fully-discharged to fully-charged:
3.1 IMPORTANT: READ THE CHARGER HANDBOOK BEFORE
ATTEMPTING TO CHARGE THE BATTERY.
3.2 NOTE: The battery is put into ‘ship mode’ prior to transit.
It can be activated by connecting it to a charger that is
powered-up, or by linking it to a battery that is already active.
3.3 Suitable chargers include:
PAGlink PL16 Charger 2-positions Gold Mount or V-Mount
PAGlink PL16+ Charger 4-positions Gold Mount or V-Mount
PAGlink Micro Charger 1-position Gold Mount or V-Mount
Sony Li-Ion chargers and some Anton Bauer Li-Ion chargers may
also be suitable.
3.4 Mini PAGlink batteries can be charged individually or linked, to
other MPL batteries regardless of their rated capacity or state of
charge. Up to 10 MPL batteries can be linked for full-charging on
each position. MPL batteries can be partially charged and
discharged without suffering any damaging effects.
3.5 Older PAG Li-Ion chargers will charge linked batteries to 100% if
the difference in state of charge between them is less than 40% at
the start. Batteries can be precharged individually, until they are
within 40%, and then linked for a full charge.
Capacity PL16 Micro Charger
50Wh 01:15 02:00
100Wh 01:30 04:00
200Wh 03:00 08:00
300Wh 04:45 12:00
400Wh 06:00 16:00
600Wh 09:00 24:00
800Wh 12:00 -
1600Wh 24:00 -
