6
2
Fan
Do not block the outlet of the fan, otherwise the internal
heat dissipation of the machine will lead to excessive
internal temperature.
3
Display area
TFT color screen display, output Settings and
measurement results.
4
0-9 and .
Esc
< >
Enter
Number and dot key:input number;
Esc key: return to the previous page.
< > Cursor movement key: Use to move the cursor left
and right to the desired parameter position.
Enter: Confirm parameter setting.
5
Knob
Users can turn the knob to enter programming
information or options.
6
CH2 Output
Terminal
Output connection of Channel 2.
7
CH1 Output
Terminal
Output connection of Channel 1.
8
CURR
Current setting key: press it to enter the current setting
mode, at the same time, user can input current value by
numeric box or knob.
SHIF+CURR: quick setting for OCP.
In LIST mode, this button is defined as the manual
trigger button for channel 2.
9
CH1:ON/OFF
Control the output status of CH1: ON or OFF.
CH2:ON/OFF
Control the output status of CH2: ON or OFF.
10
VOLT
Voltage setting key: press it to enter the voltage setting
mode, at the same time, user can input voltage value by
numeric box or knob.
SHIF+VOLT: quick setting for OVP.
In LIST mode, this button is defined as the manual
trigger button for channel 2.
11
SHIFT
Reuse function keys.
