Specifications
82
Specification
Values
HDMI IN
Signal Formats
4K (4096x2160): 23.98/24/25/29.97/30P
UHD (3840x2160): 23.98/24/25/29.97/30P
2K (2048x1080): 23.98/24/25/50
HD (1920x1080): 23.98/24/25/29.97/30/50/59.94/60P,
50/59.94/60I
HD (1280x720): 50/59.94/60P
SDI IN/OUT
Signal Formats
2K (2048x1080): 23.98/24/25/29.97/30/50/59.94/60P,
23.98/24/25/29.97/30Psf
HD (1920x1080): 23.98/24/25/29.97/30/50/59.94/60P,
50/59.94/60I
HD (1280x720): 50/59.94/60P
Connector
BNC per IEC 169-8
Impedance
75Ω
Return Loss
>18 dB 5 to 270 MHz
>15 dB 270 MHz to 1.5 GHz
>10 dB up to 3 GHz
Maximum Signal Level
800 mV pk-pk 10%
Signal Amplitude
800 mV pk-pk 10%
DC Offset
0 V ±0.5 V
Overshoot
<10%
Jitter
<0.2 UI
Rise/Fall Time
<700 ps for SD
<270 ps for 1.5 Gb/s HD
<135 ps for 3 Gb/s HD
Extinction Ratio
>8
Back Reflection
<-14 dB
2.
Dimensions
The description of the product dimensions is shown as in the following figures:
◼ Mega 15S
