Panel Layout and Device Features
60
◼ Set Key button as PIP: set
Key Typ
e →
type
as PIP.
◼ Set signal source for PIP: select
PIP
→
source
→
PIP
item.
◼ Set frame size of PIP: select
PIP
→
size/position
→
PIP
size
item.
◼ Set frame position of PIP: select
PIP
→
size/position
→
X Position
/
Y Position
item.
◼ Set frame width of PIP: select
PIP
→
border
→
Width
item.
◼ Set frame color: select
PIP
→
color
→
Hue/Saturation/Brightness
items.
Here's how to generate the above PIP key:
Step 1 Set the type of upstream keyer as PIP
Press MENU to display the main menu, and scroll the menu knob to select
Key
Type
→
type
→
Type
as
PIP
, KEY button will be assigned as PIP.
Step 2 Load PIP on air
Press
KEY
button to enable PIP on the preview output.
Step 3 Set PIP Source
Then set PIP source. Press MENU to display the main menu, and scroll the menu
knob to select
PIP
→
source
→
PIP
as
In 1, In 2, etc.
Step 4 Set PIP Parameters
To refine the PIP key, adjust parameters for PIP, such as position, size, mask
settings, border color, etc.
Refer to "5.1.7 PIP Settings" for more details about PIP parameters.
4.1.3.15 Set and Adjust Mask
Masking can be used as a creative setting to build rectangular cut outs on screen.
Luma Key, linear key, Chroma key, Pattern key and PIP key menus all have a mask
setting that can be used to crop edges in the designed video signal. The mask
submenu consists of left, right, top and bottom crop controls. Refer to the
corresponding menu settings for more details about mask parameters.
