[ USER MANUAL ]
5. SPECIFICATION
5.1 General Specifications
*HDMI In / Out, DP In: Not support the HDCP
**Specifications and design are subject to change without notice.
Model Name R4N46UNF/UHF R4N46ENF/EHF R4N55UNF/UHF R4N55ENF/EHF
Bezel Width BEZEL to BEZEL 3.5 1.7 3.5 1.7
Display
Screen Size (inch) 46.0" 46.0" 55.0" 55.0"
Resolution 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080
Pixel Pitch (mm) 0.530 x 0.530 0.530 x 0.530 0.630 x 0.630 0.630 x 0.630
Brightness 500 cd/m² 700 cd/m² 500 cd/m² 700 cd/m² 500 cd/m² 700 cd/m² 500 cd/m² 700 cd/m²
Contrast Ratio 3500:1 4000:1 4000:1 4000:1
Aspect Ratio 16:9 16:9 16:9 16:9
Viewing Angle (H/V) 178/178 178/178 178/178 178/178
Display Color 16.7 million 16.7 million 16.7 million 16.7 million
Response Time 8 ms 8 ms 8 ms 8 ms
Video System NTSC/PAL NTSC/PAL NTSC/PAL NTSC/PAL
Interface
*DP In / Out
1 / 1 1 / 1 1 / 1 1 / 1
*HDMI In 3 3 3 3
DVI In / VGA In 1/1 1/1 1/1 1/1
RS-232 In/Out 1/1 1/1 1/1 1/1
USB(FW UPDATE) 1 1 1 1
Audio Out 1 1 1 1
Remote Control Y Y Y Y
Special
Features
RS-232 Control
Monitor OSD &
Multi Vision
Monitor OSD &
Multi Vision
Monitor OSD &
Multi Vision
Monitor OSD &
Multi Vision
Deinterlacing Y Y Y Y
Auto Pixel Shift Y Y Y Y
One Stretch Image
by Edge Set
Y Y Y Y
General
Outline Dimension
1021.98 x 576.57 x 87
(40.24" x 22.7" x 3.43")
1020.02 x 574.61 x 85.4
(40.16" x 22.62" x 3.36")
1213.5 x 684.3 x 87.5
(47.77" x 26.94" x 3.44")
1211.602 x 682.402 x 86.9
(47.7" x 26.866" x 3.42")
Net Weight(Kg/lb) 21Kg (46.3 lbs) 21Kg (46.3 lbs) 26Kg (57.32 lbs) 26Kg (57.32 lbs)
Cabinet Color Black Black Black Black
Cabinet Material Electro-Galvanized Steel Electro-Galvanized Steel Electro-Galvanized Steel Electro-Galvanized Steel
Power Consumption < 121 W < 162 W < 121 W < 162 W < 167 W < 242 W < 167 W < 242 W
Electrical Ratings AC 100~240 V (50/60Hz) AC 100~240 V (50/60Hz) AC 100~240 V (50/60Hz) AC 100~240 V (50/60Hz)
Storage Temperature
-20 ~ 60°C / -4 ~ 140°F -20 ~ 60°C / -4 ~ 140°F -20 ~ 60°C / -4 ~ 140°F -20 ~ 60°C / -4 ~ 140°F
VESA Mounts Size
(mm)
600 x 400 600 x 400 600 x 400 600 x 400
Video Wall WFS, WES, WSD, WSR WFS, WES, WSD, WSR WFS, WES, WSD, WSR WFS, WES, WSD, WSR
Stand Alone WB-4063 WB-4063 WB-4063 WB-4063
