NVE 6000 / NVE 6100
20
CARE AND MAINTENANCE
Reversing the rotation of the door of your appliance
This refrigerator has the ability to open the door from either the left or right side. The unit is
delivered with the door opening from the left side.
If you need to open the door from the opposite side, it is recommended that you call your local
authorized service agent to perform this conversion or consult a technician. Before reversing the
door, you must ensure that the appliance is unplugged and empty. It is recommended to use a
Phillips screwdriver and a wrench.
1. Remove the top hinge cover (2).
2. Remove the screws (1) that secure the top hinge (3) to the appliance, then remove the top
hinge.
3. Lift the door and place it on a padded surface to prevent scratching.
4. Remove the screws (7) securing the bottom hinge (6), then remove the bottom hinge.
5. Remove the foot (5) and transfer it to the opposite side.
6. Remove the cover plate (4) to the opposite side.
7. Before installing the bottom hinge, remove the screw (8) and reverse the direction of the
bottom hinge. Then install the bottom hinge on the opposite side with the screws.
