NCO 3090
29
Choose a location free from heat sources. Keep the refrigerator away from direct sunlight and other heat-
generating appliances.
Choose a dry, well-ventilated location where there is no corrosive air.
To improve the efficiency of the cooling system and save energy, good ventilation is essential around the
appliance to dissipate heat. Therefore, there should be sufficient free space around the refrigerator.
Place the appliance against a wall with a 15 cm clearance. You should leave a 30 cm clearance on each side
and 20 cm at the top.
Level the unit
- To level the unit, adjust the 2 front legs of the device.
- If the unit is not level, the door and the magnetic seal will not match.
Door opening direction
Tools needed: Phillips screwdriver/Flathead screwdriver/Hex wrench.
Warning
- If you wish to reverse the door swing, we recommend that you contact a qualified technician. You should
only attempt to reverse the door if you believe you are qualified to do so.
- Make sure the unit is unplugged and empty.
- Adjust the two leveling legs to their highest position.
- To remove the door, if necessary, tilt the unit backward. Rest the unit on a solid object to prevent it from
sliding during the door reversal process.
- All removed parts must be saved for reinstallation of the door.
- Do not place the unit horizontally, as this may damage the cooling system.
- It is recommended that 2 people operate the appliance during assembly.
1. Remove the plastic cover from the top door hinge.
2. Loosen the three screws on the bottom bracket.
3. Remove the leg from the opposite side.
4. Slide the appliance door about 15 cm off the top hinge pin and remove it from the appliance.
5. Remove the two screws from the top bracket and replace it on the other side. First, remove the
plastic caps from the other side.
6. Slide the appliance door back onto the top hinge. Make sure it's in the correct position.
7. Screw the bottom hinge into position on the new side.
8. Replace the plastic cover, snapping it back into position on the door hinge until it clicks.
9. Check that the door is aligned horizontally and vertically and that the seals are closed on all sides
before tightening the bottom hinge.
10. Readjust the leveling legs.
