CP 138105 CP 140105
15
Remove the seat post pin and upper hemisphere
Slide the support bar through the gap in the bowl and coupling
cover.
Pass the cables through the support bar.
Replace the support bar hemisphere.
Place the pin through the holes to secure the support bar to the
fan body.
CAUTION: It is very important to ensure that the flange pin is
correctly installed and secured. Improper pin fastening can
cause the fan to fall.
Tighten the screws securely.
Carefully lift the fan and place the tilting support bar into the
suspension bracket attached to the ceiling. Make sure the ball
slot is properly aligned with the tab on the support bar.
WARNING
The fan should be hung with at least 230 cm of clearance from
the floor to the blades.
