CP 139092
16
Carefully lift the fan and place the tilting support bar into the
suspension bracket attached to the ceiling. Make sure the ball
slot is properly aligned with the tab on the support bar.
WARNING
The fan should be hung with at least 230 cm of clearance from
the floor to the blades.
Slide the remote receiver into the holder
Connect the remote control receiver by matching the wire
colors, following the diagram in the next section of the manual.
Insert the screws and loosely tighten. Place the cup in place as
shown and turn counter-clockwise. Be careful not to cut any
wires when snapping the cup into place.
Tighten the screws.
