English
18
SETUP AND INSTALLATION
Stand Mounting Installation (Optional)
The stand mount kit includes the following items:
Pen tray (x1) Wheel (x4) Screw J (x16) Screw H (x4)
Nut G (x4) Washer G1 (x4) Split Ring Lock
Washer G2 (x4)
Stand pole (x2) Stand base (x1) Screw K (x4) Washer K1 (x4) Nut K2 (x4)
To mount the IFP on the stand, complete the following steps:
1. Install the dual mounting brackets on the rear of the IFP. Then secure the brackets with four
screws (A).
A
Note: Dual mounting brackets, wall mount, and screws (A) are included in the wall mount kit. Refer to
“Wall Mounting Installation” on page 14.
