English
11
INTRODUCTION
Rear View
Audio In
VGA InSPDIF Out HDMI Out
BATTERY
Line OutRS232
Android
USB3.0
USB3.0
Touch
HDMI In 1HDMI In 2
DP In
LAN Out
LAN In
USB3.0
Public
USB3.0
Public
Type C
21
18
17
15
13
14
20
19
16
5 6 1098 11 127
3
2
4
1
No. Item No. Item
1. Handles (x2) 12. Audio In
2. Mounting holes for wall mount 13. LAN Out
3. AC In 14. LAN In
4. Power Switch 15. DP In
5. RS232 In 16. HDMI In 2 / HDMI In 1
6. Lithium Battery(3*) 17. USB 3.0 Touch
7. Line Out 18. USB Type-C In (PD 15W(2*))
8. SPDIF Out 19. USB 3.0 x2
9. HDMI Out (1*) 20. Wi-Fi dongle slot
10. Android USB 3.0 21. OPS slot
11. VGA In
Note:
• Side USB 3.0 ports are full channel USB ports. USB ports can be used irrespective of the chosen input
source.
• (1*) 4K2K compatible HDMI distributor.
• (2*) USB type-C port supports DisplayPort 1.2 and power delivery (15W).
• When recording while using a source other than Android, always connect the external USB devices,
for example the camera, to the Android USB port on the rear side of the IFP. If you connect to the non-
embedded USB port, image and sound will not be recorded.
• (3*) Supplies power to the system clock while the IFP is not connected to the power source.
