2-3

1

2

Installation and Connections

Controller Wiring

 IO-Link connection (when using an IO-Link cable)

IO-Link connection

①

③

④

Main circuit

L+

C/Q

M

IO-Link Master

No.

Wire

color

M12 connector

pin No.

Description

①

Brown ①

③

Black ④

④

Blue ③

L+

②

−−*

C/Q

M

IO-Link cable lead wire/

connector pin functions

The input wire is replaced with

process output data.

*

M12 connector pin No.

②①

④③

*

⋈

is not used.
