1-4
General Description
z Alarm output (upper/lower limit settings) (Refer to page 5-26.)
A designated temperature range can be set as the threshold, and an alarm can be output when the
measured temperature is outside of that range.
z Detection of rapid temperature changes (edge detection) (page 5-21)
Edge detection is provided, and detects when rapid temperature changes occurred.
Because slow temperature changes are ignored, it is possible to only detect errors caused by temperature
changes occurring within a short period of time.
z Hold display (Refer to page 5-13.)
Instead of displaying the measured temperature in real time, the maximum/minimum temperature displays
can be retained (peak hold, valley hold), and the measured value can be held (sample hold) when real-time
display is not needed.
Various user-friendly functions
z Head internal temperature display (Refer to page 3-3.)
In addition to the temperature of the measurement target, the head internal temperature is also continuously
displayed. This allows use while checking the effects of the ambient temperature.
z Saving/selecting (calling) four types of settings (Refer to page 5-6.)
4 ch are installed for the bank function which can select (call) setting contents.
During setup and at other times, it is not necessary to reconfigure the settings when the emissivity or other
measurement condition changes. Instead, it can be handled simply by selecting the preconfigured bank.
z Notification of maintenance timing (Refer to page 7-2.)
Notification of maintenance timing can be provided when the preset period has elapsed for the timing of
optical system cleaning, calibration, or other maintenance.
z The sensor head and controller can be replaced individually (Refer to page 7-3.)
Because the sensor head and controller are calibrated individually, either can be replaced if a malfunction
occurs.
Because the settings are saved separately for the sensor head and controller, operation can be restarted
with the minimal necessary reconfiguration after replacement.
z Connection test (Refer to page 5-25.)
A physical test can be performed to determine whether or not signals are actually being output from the
input/output cable.
z Trend graph display (Refer to page 3-6.)
A trend graph of the measured temperature can be displayed covering up to 24 hours.
