Hardware Installation Guide

OpenVox Communication Co. Limited. URL: www.openvox.cn 6/27

• Push button: for mode setting switch, accessing a programmable GPI, active low

means switch is pressed

• PCIe Interface : PCIe p6-x4 Golden Finger

• Expansion: 2 MiniPCIe slot

• Connectivity: Up to 3 Ethernet channels (10/100/1000Mbps speed)

3 PCIe Ethernet controller

Support PXE (for remote booting )

• I/O: 1*DB9 serial port, for debug console usage ,RS232, 3*USB 2.0 port

• Board size: 6 x 6" (152.4 x 152.4 mm)

• Temperature: 0°C to 60°C (contact factory for more temp. options)

• Firmware: AMI BIOS

• PCB layer: 8

•Power dissipation: ~7.8W

condition:1GB memory, unattached HDD, unattached MiniPCIe card , Attached

4GB CF card, under Centos

Other condition:

8.1W@ condition:1GB memory, unattached HDD, unattached MiniPCIe card ,

attached 4GB CF card, under WindowsXP

9W@ condition:1GB memory, attached 2.5inch HDD, unattached MiniPCIe card ,

unttached CF card, under Centos

Ordering information

Standard available options:

Name

Function

Operating Temperature

IPC110B01

Z530P/3*Gigabit LAN/1 PCIe

0°C to 60°C

IPC110C01

Z510P/3*Gigabit LAN/1 PCIe

0°C to 60°C

IPC110B02

Z530P/3*Gigabit LAN/2 PCIe

0°C to 60°C

IPC110C02

Z510P/3*Gigabit LAN/2 PCIe

0°C to 60°C

IPC110B22

Z530P/3*Gigabit LAN/2G Memory

0°C to 60°C

IPC110C12

Z510P/3*Gigabit LAN/1G Memory

0°C to 60°C

IPC110B21

Z530P/3*Gigabit LAN/2G Memory/1 PCIe

0°C to 60°C

IPC110C11

Z510P/3*Gigabit LAN/1G Memory/1 PCIe

0°C to 60°C

OEM options

The following option can be configured as OEM production for larger orders:

DRAM size :1GB/2GB

CPU speed :1.3Ghz

Serveral configuration : 2* Gigabit /1* Gigabit

 Wide temperature:°C °C °C °C 0°C to 85°C (only @ Z510PT/Z520PT)
