15
•
EN
Contents
1
Introduction ............................................. 15
Package contents ..................................... 15
2
Safety Instructions ................................. 16
3
Operating Elements and Connections . 18
Models PAS 208A | 210A | 212A | 215A .. 18
Models PAS 151A | 181A ......................... 19
4
Setup ........................................................ 20
5
Connections ............................................ 23
Model PAS 208A | 210A | 212A | 215A .... 23
Model PAS 151A | 181A ........................... 23
6
Operation ................................................. 24
Setting up a Bluetooth connection ........... 24
Setting up a Bluetooth link ........................ 25
7
Cleaning and Maintenance .................... 25
Replacing the fuse .................................... 25
8
Technical Specifications ........................ 26
For product updates, documentation, software and
support please visit www.omnitronic.de. You can find
the latest version of this user manual in the product’s
download section.
© 2024 OMNITRONIC. All rights reserved.
No part of this document may be reproduced in any
form without the written permission of the copyright
owner. The contents of this document are subject to
revision without notice due to continued progress in
methodology, design, and manufacturing.
All trademarks mentioned herein are the property of
their respective owners.
D00158388,
version 1.0, publ. 23/09/2024
1 Introduction
The speaker systems of the PAS series are high-
power active speaker systems with DSP (digital
signal processor) for touring applications and
permanent installations. The speakers are
designed as 2-way systems with combined XLR
and 6.3 mm inputs for microphones, instruments
and line sources. The XLR output links further
active speaker systems. The integrated class D
amplifiers of the tops deliver an output power of
200 watts (8“& 10“), 300 watts (12“) and 400 watts
(15“), respectively. The two subwoofers are a
perfect addition and achieve a continuous output
of 700 watts. The latest Bluetooth 5.0 technology
with TWS support ensures fast and stable
wireless connections to Bluetooth audio sources
and links two PAS systems for stereo setups. All
models are equipped with low pass filters and
overload limiters. The practical EQ presets are
used for quick and application-specific sound
contouring. The rugged cabinets feature multiple
suspension points and a flange for stand
installation.
This user manual will show you how to install and
operate the PA speaker systems. Users of this
product are recommended to carefully read all
warnings in this manual and on the unit in order to
protect yourself and others from damage.
Please save this document for future needs and
pass it on to further owners.
Package contents
• Power cord
• these instructions
