Je bekijkt pagina 10 van 32
P10
Contents
W-A
W-C
W-B
3
2
1
4
7
5
6
8
9
10
Screws / Hardware for Wall Mounting (Wall Kit 38-2vC)
Part # Qty Description
W-A 2 Lag Bolts 10mm x 88mm
W-B 2 Steel Washer
W-C 2 Wall Anchor
P-B
Screws / Hardware for Product (OM10064vC)
Part # Qty Description
P-A 2
Cover Screws
P-B 2 Cable Covers
P-C 8
M6 x 5/8” Screw
P-D 8 M6 Washer
P-E 8 M6 Nylon Nut
Contents
Part # Qty Description
1 1 Complete Unit
21Wall Plate
3 1 Wall Plate Cover
4 1 Allen Wrench 5mm
51Plastic Cap
6 1 Plastic Bushing
7 1 Countersunk Screw
8 2 Tilt Adjustment Screw
9 1 Swivel Adjustment Screw
10 2 Level Adjustment Nut
11 4 VA324 Adapter
P-DP-C
P-E
11
Screws / Hardware for Flat Panel (Monitor Kit L-U-vD)
Part # Qty Description
M-A 4 Philips screws M4 x 15mm
M-B 4 Philips screws M4 x 30mm
M-C 4 Philips screws M5 x 15mm
M-D 4 Philips screws M5 x 30mm
M-E 4 Philips screws M6 x 15mm
M-F 4 Philips screws M6 x 30mm
M-G 4 Philips screws M8 x 15mm
M-H 4 Philips screws M8 x 30mm
M-I 4 Round Spacers: M6 - M8 x 5mm
M-J 4 Round Spacers: M6 - M8 x 10mm
M-K 4 Round Washers M4-M5
M-L 4 Round Washers M6-M8
M-CM-A M-E M-G M-DM-B M-F M-H M-I M-J M-K
M-L
