Screws / Hardware for Flat Panel
Part # Qty Description
M-A 4 Philips screws M4 x 15mm
M-B 4 Philips screws M4 x 30mm
M-C 4 Philips screws M5 x 15mm
M-D 4 Philips screws M5 x 30mm
M-E 4 Philips screws M6 x 15mm
M-F 4 Philips screws M6 x 30mm
M-G 4 Philips screws M8 x 15mm
M-H 4 Philips screws M8 x 30mm
M-I 4 Round Spacers: M6-M8 x 5mm
M-J 4 Round Spacers: M6-M8 x 10mm
M-K 4 Round Washers: M4-M5
M-L 4 Round Washers: M6-M8
Wall Kit
Part # Qty Description
W-A 4 Lag Bolts (8mm x 65mm)
W-B 4 Steel Washer (18mm x 8.5mm x 1.5mm)
W-C 4 Wall Anchor (10mm OD x 8mm ID)
Screws/Hardware for Product
Part # Qty Description
P-A 1 Phillips Head Screw M6x8mm
P-B 4 Round Head Screw M6x13mm
P-C 8 M6 Nylock Nut
Screws/Hardware for Product
Part # Qty Description
P-D 1 Cable Wrap
Screws/Hardware for Product
Part # Qty Description
P-F 1 65mm Washer
P-G 1 25mm Washer
P-H 1 Spring Disk
P-I 1 16mm Bearing
P-J 1 M8 Hex Nut
P-K 1 M8 Hex Screw
P-L 2 Cable Tie
P-M 1 Tubing
Screws/Hardware for Product
Part # Qty Description
P-Q 1 8mm 1/4 Drive Deep Socket
CONTENTS
P-F P-J
P-K
P-IP-HP-G
P-L P-M P-Q
P-A P-DP-CP-B
W-A W-CW-B
M-E M-HM-GM-f
M-A M-DM-CM-B
M-I M-LM-KM-J
