Je bekijkt pagina 3 van 32
P3
P-G P-H
X1 X1
OPEN WRENCH ALLEN WRENCH
CONTENTS / CONTENIDO
P-A
P-B P-C
P-D P-E P-F
5
3
4
2
1
CONTENTS
Wall frame cover / Cobertura del marco de pared15
Glass bracket / Escuadra para vidrio24
Glass shelf / Repisa de vidrio13
Glass support shelf / Soporte de repisa de vidrio12
Wall frame / Marco de pared11
DescriptionQtyPart #
SCREW / HARDWARE PACK FOR WALL MOUNTING /
TORNILLOS/HARDWARE PARA EL MONTAJE EN LA PARED
SCREW / HARDWARE PACK FOR PRODUCT /
TORNILLOS/ HARDWARE DE LA PANTALLA
W-A
W-B
X3
X3
Phillips Wood Screws
Concrete Wall Anchors
X2 X2 X2X2 X2 X6
WASHER NYLON NUT STANDOFF* M5 SCREW* M4 SCREW COVER CLIP
CONTENTS / CONTENIDO
*for double wall shelf installation only
Wall Anchor (8mm OD x
6mm ID)
3W-B
Phillips Wood Screws
(6mm x 65mm)
3W-A
Description
QtyPart #
Screws / Hardware for Wall Mounting
(Wall Kit 12-3vB)
ALLEN WRENCH1P-H
OPEN WRENCH1P-G
COVER CLIP6P-F
M4 PHILLIPS SCREW2P-E
M5 PHILLIPS SCREW*2P-D
STANDOFF*2P-C
NYLON NUT2P-B
WASHER2P-A
Description
QtyPart #
Screws / Hardware for Product
(OM1100441vA)
OM1100441vA
WALL KIT 12-3vB
CAUTION!
PH#3 ONLY
