•Material:highquality,impactandUV-resistantABScolourRAL9010.

•Designfrontcoverremovableforcleaningwithouttheuseoftools.

•Rearreinforcementringtopreventspigotdeformationduringinstallation.

•High efﬁciency aerodynamic fan with “winglet” blades to optimise quietness and

efﬁciency.

•SinglephaseECBrushlessmotorwithintegralthermalprotection.

•Motormountedonhighqualityballbearings.

•Thefanisdoubleinsulated:noearthconnectionisrequired.

•Tricklespeedselectableduringinstallation:6,8,13l/soroff.

•Optiontoboostfromtrickle(orfromoff)throughLSconnection.

•Installationtypeselectionavailable(throughwallorducted).

•TimerandIntegralHumidistatversionsavailable.

•IPX4degreeofprotection.

•Powersupply220Vto240V~50Hz.

TECHNICAL SPECIFICATIONS

•Iftheenvironmentin whichthe productis installedalso housesa fuel-operating

device(waterheater,methanestoveetc.,thatisnota“sealedchamber”type),it

isessentialtoensureadequateairintake,toensuregoodcombustionandproper

equipmentoperation.

•Installtheproductsothattheimpellerisnotaccessiblefromtheairoutletsideas

veriﬁedbycontactwiththeTestFinger(testprobe“B”ofthenormEN61032) in

compliancewiththecurrentsafetyregulations.

•Ceilinginstallation

 Inorder toguarantee theIPX4 degreeof protectionagainst moisturein caseof

ceilinginstallation,usetheappropriateceilingmountkit,whichisnotincluded.Use

onlytherearentryholeforsupplycables.Ifthereisapossibilityofcondensation

alongtheairdischargeduct,provideadrainagesystemtopreventcondensation

fromdischargingintotheenvironmentthroughthefan.

 Attention:donotmounttheproductontheceilingwithoutthiskit.

•Windowinstallation

 Incaseofwindowinstallationitisnecessarytousetheappropriatewindowkit,

whichisnotincluded.

 Attention:donotmounttheproductonthewindowwithoutthiskit.

INTRODUCTION

SITALISFE100isadecentralisedmechanicalventilationunitdesignedtoensureair

extractioninsmall/medium-sizedrooms.

Suitableforairdischargedirectlytotheoutsideorinthepresenceofshortducted

system.Wall,ceilingorwindowinstallation(fig.1).

WITH HUMIDISTAT/TIMER

Thefanisequippedwithahumiditysensor,whosethresholdisadjustablefrom50%

to95%RelativeHumidityviadedicatedtrimmer,andwithatimerwhichisadjustable

from0toapprox.30minutesviadedicatedtrimmer(ﬁg.14).

The fan runs continuously at selected trickle speed (set by the jumper switch

combination-ﬁg.15),increasesitsspeedincasethepercentageofRelativeHumidity

exceedsthesettablethreshold,andcananywaybeboostedwithadedicatedON/OFF

switch(orPIR,CO2…sensor)orwithalightswitch(ﬁg.13).

VERSIONS
