DATE:showsthecurrentdate

MODE:showstheoperationmode

SPEED:shows the selected speed

TIME:showsthetime

FILTER ALARM:showsthatltersneedtobemaintained/replaced

BOOST:showsthatBOOSTspeedisactivated

DISABLED:showsthattheCTRL-DSPisdisabled

BOOST:tomanuallyactivatetheBOOSTspeed

to move to the right when setting the Weekly Timer

FILTRO:toresettheFilterAlarm

to move to the left when setting the Weekly Timer

ESC:toexitandgobacktothepreviousmenu

OK:toentertheselectedmenu

togoDOWNwiththemenuselection

togoUPwiththemenuselection

to power on/off the ventilation unit

Fig. 7.c CTRL-DSP

IncaseofRIGHTorientation,followsinstructionsasper§3.3-Fig.3.aandFig.3.binordertogetthetemperatureprobes

operate correctly.

shows ERROR ALARM(see§7.3tocheckthetypeoferror)

shows that the Bypass is active

showsthatANTI-FROSTisactive

showsthattheIAQinputisactivated(i.e.HY,CO2)

showsthatNIGHTMODEisactivated

shows that Heating output is activated

shows that the Boost is active

shows that the weekly timer is activated

shows that the weekly timer is deactivated

shows that the SLAVE functionality is activated

7 OPERATION

WARNING

Make sure that speciﬁc warnings and cautions in Chapter 2 “Precautions” are carefully read, understood and applied!

LEFT ORIENTATION

A Intake air from outside

B Exhaust air to outside

C Supply air to inside

Extract air from inside

Fig. 7.b SITALI CXVA 400 e SITALI CXVA 550

temperature probes.

Fig. 7.a SITALI CXVA 280 temperature probes.

Some operations can be selected either from the CTRL-DSP buttons or from the menu.

c d

T12

T21 T11

T22

EXTRACT

SUPPLY

INTAKE

EXHAUST

T12

T21

T11

T22

EXTRACT

SUPPLY

INTAKE

EXHAUST
