ENGLISH
EN - 12
To access the board, remove the screws (31a) and the panel (31b) of the terminal box (31) (Fig.16).
The appliance connection MUST respect the European and national standards
and MUST be protected by a 30 mA dierential switch.
Connection to the mains supply can be carried out with xed connection or with mobile plug and
MUST be equipped with an omnipolar switch compliant with the current IEC EN standards, with
a contact opening of at least 3mm (better if equipped with fuses).
Correct connection to the ground system is essential to ensure safety of the
appliance.
Wiringdiagramkey(g.15)
H2: Watertemperatureprobe
AIR: Airtemperatureprobe
M1: Fan motor
M2: Flap motor
Y1:
Water230V-50Hzsolenoidvalve,max10W
X6: Grilleinputcontact
F1: Fuse
L: Line
N: Neutral
S2: Presence contact
A: Modbus line or presence contact input
(Yellow)
B: Modbus line or presence contact input
(Orange)
D1: Visualizationdisplay
CR: Remote control
2.11.a-Conguration
Theprintedcircuitboardmustbecongureddependingonthetypeofinstallationandbasedonparticular
operatingpreferencesofthemachine.
ThethreeselectorsJ1,J2andJ3indicateding.15mustbesetasdescribedinthenextpage:
J1. ON:innightmode,heatingworksinnaturalconvectionandirradiationmodeonly,withoutventila-
tion;Inalltheothercasesofheating,ventilationswitchesoapproximately1°Cbeforereaching
thedesiredtemperatureandcontinuesinirradiationandnaturalconvectiononlyuptothedesired
temperature.
J1. OFF:forapplianceswithoutradiantpanel:heatingoccursalwaysthroughforcedconvection,with
activationactivealsoinnightmode(atreducedspeed).
J2. ON:incoolingmode,thefanremainspoweredevenuponreachthedesiredambienttemperature.
J2. OFF:incoolingmode,thefaniddeactivateduponreachingthesettemperature.
J3. ON:forappliancestobeinstalledin2-pipessystems:theboardissetformanagementofasingle
watervalveforsummer(cooling)andwinter(heating)operation.
J3. OFF:forappliancestobeinstalledin4-pipessystems:theboardissetformanagementoftwowater
valves,oneforsummer(cooling)operationandoneforwinter(heating)operation.
The three selectors can be positioned in all the possible combinations since the respective
functions are independent from each other.
Ateachreactivation,thedisplayshowsthecodecorrespondingtothesettingoftheinternalselectorsfor
5seconds:
D1 C0 C1 C2 C3 C4 C5 C6 C7
J1 OFF OFF OFF OFF ON ON ON ON
J2 OFF OFF ON ON OFF OFF ON ON
J3 OFF ON OFF ON OFF ON OFF ON
